Holsan Orchard Sprayers
CAN 20 2000 LT. (NARROW TYPE)
TRAILED TYPE ORCHARD SPRAYING MACHINE
CAN 20 2000 LT. (NARROW TYPE)
TRAILED TYPE ORCHARD SPRAYING MACHINE
TANK: 2000 lt. anti-corrosive fiberglass tank with steel wave breaker, hydraulic mixer, lockable lid, nybolt strainer, level indicator in front and on the side and drain valve
PUMP: Imovilli M155, 5 membranes that can deliver 142 lt. (45.4 gallons)/ min. 0-50 bar
PTO SHAFT: 80° wide angle, constant velocity shaft with adjustable tow-bar
TURBO: 900 mm fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm. Contains 16 nozzles
CHASSIS: Strong steel construction chassis with steps on both sides, conveyor shield, mounted on 10.0/75-15.3 tubeless tires
CONTROLLER: Tractor mounted Braglia brand controller
RANGE: Even air distribution, 15 m left, 15 m right, 30 m total
DIMENSIONS: 1320 mm x 4430 mm x 1460 mm (W x L x H)
CAN 20 2000 LT. (LONG TYPE)
TRAILED TYPE ORCHARD SPRAYERS
CAN 20 2000 LT. (LONG TYPE)
TRAILED TYPE ORCHARD SPRAYERS
TANK: 2000 lt. anti-corrosive fiberglass tank with steel wave breaker, hydraulic mixer, lockable lid, nybolt strainer, level indicator in front and on the side and drain valve
PUMP: Imovilli P186 high pressure 6-pistons pump that can deliver 172 lt. (45.4 gallons)/min. 0-50 bar
PTO SHAFT: 80° wide angle, constant velocity shaft with adjustable tow-bar
TURBO: 900 mm fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm. Contains 16 nozzles
CHASSIS: Strong steel construction chassis with steps on both sides, conveyor shield, mounted on 10.0/75-15.3 tubeless tires
CONTROLLER: Tractor mounted Braglia brand controller
RANGE: Even air distribution, 15 m left, 15 m right, 30 m total
DIMENSIONS: 1720 mm x 4400 mm x 1350 mm (on low) (W x L x H)
CAN 20 2000 LT.
TRAILED TYPE ORCHARD SPRAYER
CAN 20 2000 LT.
TRAILED TYPE ORCHARD SPRAYER
TANK: 2000 lt. anti-corrosive fiberglass tank with steel wave breaker, hydraulic mixer, lockable lid, nybolt strainer, level indicator in front and on the side and drain valve
PUMP: Imovilli M155 high pressure 5-diaphragm pump that can deliver 142 lt. (37.5 gallons)/min. 0-50 bar
PTO SHAFT: 80° wide angle, constant velocity shaft with adjustable tow-bar
TURBO: 900 mm fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm. Contains 16 nozzles
CHASSIS: Strong steel construction chassis with steps on both sides, conveyor shield, mounted on 10.0/75-15.3 tubeless tires
CONTROLLER: Tractor mounted Braglia brand controller
RANGE: Even air distribution,12 m left, 12m right, 24 m total
DIMENSIONS: 1720 mm x 4030 mm x 1460 mm (W x L x H) WEIGHT: 620 Kg
CAN 20 900 SF 2000 LT.
TRAILED TYPE ORCHARD SPRAYERS
CAN 20 900 SF 2000 LT.
TRAILED TYPE ORCHARD SPRAYERS
TANK: 2000 lt. anti-corrosive fiberglass tank with steel wave breaker, hydraulic mixer, lockable lid, nybolt strainer, level indicator in front and on the side and drain valve
PUMP: Imovilli M155 high pressure 5-diaphragm pump that can deliver 142 lt. (37.5 gallons)/min. 0-50 bar
PTO SHAFT: 80° wide angle, constant velocity shaft with adjustable tow-bar
TURBO: 900 mm super-fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm. Contains 14 / 16 nozzles
CHASSIS: Strong steel construction chassis with steps on both sides, conveyor shield, mounted on 10.0/75-15.3 tubeless tires
CONTROLLER: Tractor mounted Braglia brand controller.
RANGE: Even air distribution 12 / 15 m left, 12 / 15 m right, 24 / 30 m total
DIMENSOINS: 1720 mm x 4000 mm x 1460 mm (W x L x H) WEIGHT: 650 Kg
CAN 15 KASIRGA 1500 LT.
TRAILED TYPE ORCHARD SPRAYER
CAN 15 KASIRGA 1500 LT.
TRAILED TYPE ORCHARD SPRAYER
TANK: 1500 lt. anti-corrosive fiberglass tank with steel wave breaker, hydraulic mixer, lockable lid, nybolt strainer, level indicator in front and on the side and drain valve
PUMP: Imovilli M155 high pressure 5-diaphragm pump that can deliver 142 lt. (37.5 gallons)/min. 0-50 bar
PTO SHAFT: : 80° wide angle, constant velocity shaft with adjustable tow-bar
TURBO: 900 mm fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm. Contains 16 nozzles
CHASSIS: Strong steel construction chassis with steps on both sides, conveyor shield, mounted on 10.0/75- 15.3 tubeless tires
CONTROLLER: Tractor mounted Braglia brand controller
RANGE: Even air distribution, 15 m left, 15 m right, 30 m total
DIMENSIONS: 1720 mm x 3870 mm x 1340 mm (W x L x H) WEIGHT: 628 Kg
CAN 11 1000 LT.
TRAILED TYPE ORCHARD SPRAYERS
CAN 11 1000 LT.
TRAILED TYPE ORCHARD SPRAYERS
TANK: 1000 lt. anti-corrosive fiberglass tank with hydraulic mixer, lockable lid, nybolt strainer, level indicator in front and on the side and drain valve
PUMP: Imovilli P186 high pressure 6-pistons pump that can deliver 172 lt. (45.4 gallons)/min. 0-50 bar
PTO SHAFT: 80° wide angle, constant velocity shaft with adjustable tow-bar
TURBO: 800 mm fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm. Contains 14 nozzles
CHASSIS: Strong steel construction chassis with steps on both sides, conveyor shield, mounted on 235xR15 tires
CONTROLLER: Tractor mounted Braglia brand controller
RANGE: Even air distribution,12 m left, 12m right, 24 m total
DIMENSIONS: 1500 mm x 3490 mm x 1270 mm (W x L x H) WEIGHT: 534 Kg
CAN 11 KASIRGA 900P 1000 LT.
TRAILED TYPE ORCHARD SPRAYER
CAN 11 KASIRGA 900P 1000 LT.
TRAILED TYPE ORCHARD SPRAYER
TANK: 1000 lt. anti-corrosive fiberglass tank with hydraulic mixer, lockable lid, nybolt strainer, level indicator in front and on the side and drain valve
PUMP: Imovilli M155 high pressure 5-diaphragm pump that can deliver 142 lt. (37.5 gallons)/min. 0-50 bar
PTO SHAFT: 80° wide angle, constant velocity shaft with adjustable tow-bar
TURBO: 900 mm fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm. Contains 16 nozzles
CHASSIS: Strong steel construction chassis with steps on both sides, conveyor shield, mounted on 10.0/75-15.3 tubeless tires
CONTROLLER: Tractor mounted Braglia brand controller
RANGE: Even air distribution, 15 m left, 15 m right, 30 m total
DIMENSIONS: 1540 mm x 3450 mm x 1285 mm (W x L x H) WEIGHT: 560 Kg
CAN 20 TOWER 2000 LT.
TRAILED TYPE TOWER ORCHARD SPRAYERS
CAN 20 TOWER 2000 LT.
TRAILED TYPE TOWER ORCHARD SPRAYERS
TANK: 2000 lt. anti-corrosive fiberglass tank with steel wave
breaker, hydraulic mixer, lockable lid, nybolt strainer, level indicator
in front and on the side and drain valve
PUMP: Imovilli M155 high pressure 5-diaphragm pump that can
deliver 142 lt. (37.5 gallons)/min. 0-50 bar
PTO SHAFT: 80° wide angle, constant velocity shaft with
adjustable tow-bar
TURBO: Tower type 900 mm super-fan with conveyor, 18 stainless
steel even distribution blades with gearbox set to 1950-2450 rpm.
Contains 20 nozzles
CHASSIS: Strong steel construction chassis with steps on
both sides, conveyor shield, mounted on 10.0/75-15.3
tubeless tires
DIMENSIONS:1720 mm x 3930 mm x 2140 mm (W x
L x H)
WEIGHT: 750 Kg
SUPER-MIL-4 400 LT.
MOUNTED TYPE ORCHARD SPRAYER
SUPER-MIL-4 400 LT.
MOUNTED TYPE ORCHARD SPRAYER
TANK: 400 lt. anti-corrosive fiberglass tank with hydraulic mixer, lockable lid, nybolt strainer, level indicator and drain valve
PUMP: Imovilli M135 high pressure 5-diaphragm pump that can deliver 115 lt. (30.4 gallons)/min. 0-50 bar
PTO SHAFT: Standard, constant velocity shaft with adjustable tow-bar
TURBO: 8 blades 800 mm fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm
CONTROLLER: Tractor mounted Braglia brand controller
RANGE: Even air distribution, 8 m left, 8 m right, 16 m total
DIMENSIONS: 1730 mm x 1460 mm x 1350 mm (W x L x H) WEIGHT: 320 Kg
CAN 20 KANON 2000 LT.
TRAILED TYPE ORCHARD SPRAYER
CAN 20 KANON 2000 LT.
TRAILED TYPE ORCHARD SPRAYER
TANK: 2000 lt. anti-corrosive fiberglass tank with steel wave breaker, hydraulic mixer, lockable lid, nybolt strainer, level indicator in front and on the side and drain valve
PUMP: Imovilli M155 high pressure 5-diaphragm pump that can deliver 142 lt. (37.5 gallons)/min.
PTO SHAFT: Standard, constant velocity shaft with adjustable tow-bar
TURBO: Canon type with 6 nozzles at the tip, 6 nozzles on the side, total of 12 nozzles. Head can be adjusted 45°. Dual rotors. Can be used to spray a distance of 50 meters on a non-windy day with a 70 hp tractor. Gearbox set to 1950-2450 rpm.
CHASSIS: Strong steel construction with steps
DIMENSIONS: 2720mm x 4020 mm x 3000 mm (W x L x H) WEIGHT: 730 Kg
CAN 600 KANON 600 LT.
MOUNTED TYPE ORCHARD SPRAYER
CAN 600 KANON 600 LT.
MOUNTED TYPE ORCHARD SPRAYER
TANK: 600 lt. anti-corrosive fiberglass tank with hydraulic mixer, lockable lid, nybolt strainer, level indicator and drain valve
PUMP: Imovilli M135 high pressure 5-diaphragm pump that can deliver 115 lt. (30.4 gallons)/min. 0-50 bar
PTO SHAFT: Standard, constant velocity shaft with adjustable tow-bar
TURBO: Canon type with 6 nozzles at the tip, 6 nozzles on the side, total of 12 nozzles. Head can be adjusted 45°. Dual rotors. Can be used to spray a distance of 50 meters on a non-windy day with a 70 hp tractor. Gearbox set to 1950 – 2450 rpm
CHASSIS: Strong steel construction with steps
DIMENSIONS: 1580 mm x 1460 mm x 2500 mm (W x L x H) WEIGHT: 535 Kg
HOLSAN CAN 600 KANON WITH ROTATING HEAD
MOUNTED TYPE ORCHARD SPRAYER
HOLSAN CAN 600 KANON WITH ROTATING HEAD
MOUNTED TYPE ORCHARD SPRAYER
TANK: Mounted type 600 and 800 lt., trailed type 1000 lt – 1500 lt – 2000 lt. capacity fiberglass tank, hydraulic mixer, lockable lid, nybolt strainer, level indicator and drain valve
PUMP: Imovilli M135 high pressure 5-diaphragm pump that can deliver 115 lt. (30.4 gallons)/min. 0-50 bar
PTO SHAFT: Standard, constant velocity shaft with adjustable tow-bar
TURBO: Canon type with 6 nozzles at the tip, 6 nozzles on the side, total of 12 nozzles. Head can be adjusted 45°. Dual rotors. Can be used to spray a distance of 50 meters on a non-windy day with a 70 hp tractor. Gearbox set to 1950-2450 rpm.
CHASSIS: Strong steel construction
CAN 600 - 600 LT.
MOUNTED TYPE ORCHARD SPRAYER
CAN 600 - 600 LT.
MOUNTED TYPE ORCHARD SPRAYER
TANK: 600 lt. anti-corrosive fiberglass tank with hydraulic mixer, lockable lid, nybolt strainer, level indicator and drain valve
PUMP: Imovilli M135 high pressure 5-diaphragm pump that can deliver 115 lt. (30.4 gallons)/min. 0-50 bar
PTO SHAFT: Standard, constant velocity shaft with adjustable tow-bar
TURBO: 8 blades 800 mm fan with stainless steel conveyor with gearbox set to 1950 – 2450 rpm.
CONTROLLER: Tractor mounted Braglia brand controller
RANGE: Even air distribution, 8 m left, 8 m right, 16 m total
DIMENSIONS: 1730 mm x 1460 mm x 1580 mm (W x L x H) WEIGHT: 347 Kg
Protecting Crops with Orchard Sprayers
In the intricate world of agriculture, the efficient application of plant protection products plays a pivotal role in crop management and yield optimization. orchard sprayers emerge as indispensable tools. By harnessing the power of Holsan orchard sprayer models, farmers can bolster plant growth, combat pests and diseases, improve crop quality, and enhance harvest yields.
Unveiling The Technology of Orchard Sprayer for Agriculture
Holsan’s orchard sprayers revolutionize farming practices by delivering a higher-speed airflow and smaller droplets for more homogeneous application. By ensuring superior coverage and enhanced absorption of applied substances, Holsan orchard sprayer models elevate the efficiency of crop protection, setting a new standard for precision agriculture.
Holsan's Orchard Sprayers: A Beacon of Quality and Reliability
For farmers seeking top-tier models of orchard sprayers, Holsan emerges as the premier destination. With a focus on utilizing premium materials, employing skilled technicians, and fostering ongoing product advancement, Holsan offers top-quality orchard sprayers.
Featuring patented turbo atomizer technology, advanced safety features, and compliance with regulatory standards, Holsan’s orchard sprayer models embody reliability and performance, earning the trust of farmers worldwide.
For more information please contact us at [email protected] or via our whatsapp hotline +905337467457
